Lexmark MS725 Service Manual

Maintenance
Inspection guide
The purpose of this inspection guide is to aid you in identifying the intervals, based on page count, at which
parts must be inspected (for visible physical damage), cleaned, or replaced.
If any unsafe conditions exist, find out how serious the hazard could be and if you can continue before you
correct the hazard.
As you service the machine, check for the following:
• Damaged, missing, or altered parts, especially in the area of the On/O switch and the power supply
• Damaged, missing, or altered covers, especially in the area of the top cover and the power supply cover
• Possible safety exposure from any non-Lexmark attachments
• Printer and options are sitting flat (for example, not sitting on cables or hanging over a ledge)
• Printer is properly set on any options
Use the following table to determine when specified parts should be inspected:
MS725 Inspection guide table
PART/ITEM EVERY SERVICE
CALL
EVERY 200K NOTES
Tray insert
• Width paper guide
• Length paper guide
Inspect Replace Check for correct
positioning.
Separator pad Inspect, clean if
needed
Replace Clean with a damp
cloth.
Tray pick roller Inspect, clean Replace Clean with a damp
cloth.
MPF pick roller Inspect, clean Inspect, clean Clean with a damp
cloth.
Transfer roller Inspect Replace Ensure correct
installation.
Fuser Inspect Replace Ensure correct
installation.
Fuser wiper Inspect Replace Ensure correct
installation.
Rear door Inspect Inspect Ensure correct
operation and closure.
Duplex paper path Inspect Inspect Check for paper
fragments and
obstructions.
Toner spillage Clean Clean Remove all toner
spillage from the
printer.
4064
Maintenance
757

Lexmark MS725 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	- ppm
Display	LCD
Product color	Black, White
Display diagonal	2.4 \
Market positioning	-
Paper tray media types	Card stock, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Folio (media size), Oficio (media size), Universal
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Security features	IPSec, SNMPv3, 802.1x Authentication: MD5, MSCHAPv2, LEAP, PEAP, TLS, TTLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
USB connector	USB Type-A / USB Type-B
USB 2.0 ports quantity	2
Maximum internal memory	4608 MB
Sound pressure level (printing)	56 dB
Sound pressure level (duplex printing)	55 dB
Power consumption (off)	0.2 W
Power consumption (sleep)	1.3 W
Power consumption (printing)	720 W
Energy Star Typical Electricity Consumption (TEC)	1.28 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Other operating systems supported	IBM AIX 6.1, IBM AIX 7.1, Novell Open Enterprise Server, Solaris 10 SPARC, Solaris 11
Server operating systems supported	Windows 2000 Server, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Printing colors	Black
Maximum duty cycle	300000 pages per month
Recommended duty cycle	5000 - 75000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PDF 1.7, PPDS, PostScript 3, XML, XPS
Total input capacity	650 sheets
Total output capacity	550 sheets
Maximum input capacity	4400 sheets
Maximum number of input trays	6
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Package depth	650.2 mm
Package width	551.2 mm
Package height	563.9 mm
Package weight	30980 g

Weight and Dimensions

Depth	510.5 mm
Width	428 mm
Height	444.5 mm
