UMX-TPS-TX100 series – User's Manual 110
HDCP Setting (Output Port)
transmitted to a non-HDCP compliant display. See more information in the HDCP Management section.
Command and Response #hdcp
ç <out>.HdcpModeSetting=<HDCP_mode>
æ <out>.HdcpModeSetting=<HDCP_mode>
Parameters
Parameter description Value Parameter value
<HDCP_mode> HDCP mode
0 Auto
1 Always
Example
ç
æ
HDMI Mode Settings (Output Port)
Command and Response
ç <out>.HdmiModeSetting=<mode>
æ <out>.HdmiModeSetting=<mode>
Parameters
Parameter description Value Parameter value
<mode> HDMI mode
0 Auto
1
2 HDMI 24 bit
3 HDMI 30 bit
4
Example
ç
æ
Color Space Setting (Output Port)
Command and Response #colorspace
ç <out>.ColorSpaceSetting=<colorspace>
æ <out>.ColorSpaceSetting=<colorspace>
Parameters
Parameter description Value Parameter value
<colorspace> Color space conversion
0 Auto
1 RGB
2
3
Example
ç
æ
TPS Mode Settings
Command and Response #tpsmode
ç <port>.tpsModeSetting=<tps_mode>
æ <port>.tpsModeSetting=<tps_mode>
Parameters
Parameter description Value Parameter value
<mode> TPS mode
A Auto
H HDBaseT
L
1
2
INFO: See more information about TPS modes in the TPS Interface section.
Example
ç
æ
INFO: Use the GET command to query the parameter.
