UMX-TPS-TX100 series – User's Manual 87
LW2 Protocol Description
The receiver accepts commands surrounded by curly brackets - { } - and responds data surrounded by
round brackets - ( ) - only if a command was successfully executed. All input commands are converted to
uppercase, but respond commands can contain upper and lower case letters as well.
Legend for Control Commands
Format Explanation
<in>
<out> Output number in 1 or 2 digit ASCII format
input or output port number in 1 or 2 digit ASCII format *
<in2> Input number in 2 digit ASCII format (01, 02, 10, 12 etc.)
<out2> Output number in 2 digit ASCII format (01, 02, 10, 12 etc.)
input or output number in 2 digit ASCII format*
<loc>
<id> id number in 1 or 2 digit ASCII format
<id2> id number in 2 digit ASCII format
·
Space character (0x20)
→
Each command issued by the controller
←
Each response received from the router
* The command has the same arguments on the input ports and the output port, as well.
Instructions for the Terminal Application Usage
Terminal Application
install one of them to your control device, for example
Putty or CLI. #terminal
Establishing Connection
Follow the steps for establishing connection to the
receiver:
Step 1.
Step 2. Open the terminal application (e.g. Putty).
Step 3. Add the IP address of the device (default:
port number (10001).
Step 4. Select the Raw connection type, and open the
connection.
Once the terminal window is opened, you can enter
following sections.
LW2 protocol command communication in a terminal window
