UMX-TPS-TX100 series – User's Manual 91
Unlock Output
Unlocking an output port. The connection on output can be changed.
Command and Response
ȩ {+<<out>•<layer>}
Ȩ <out2>•<layer>
Example
ȩ
Ȩ
O1 video output port is unlocked.
INFO: The device issues the above response regardless of the previous state of the output (either it was
locked or unlocked).
View Connection State on the Output
Command and Response #crosspoint #switch
ȩ <layer>}
Ȩ <layer>•<O01>•<O02>
Parameters
O01 shows the corresponding output’s connection state.
Parameter Parameter description
<layer> Signal type of the layer
A
audio layer
V
video layer
AV
State letters
State Example
Output is locked
M Output is muted M01
U Output is locked and muted U01
Example
ȩ
Ȩ
Ȩ
I1 video input port is connected to the O1 video output port; I2 video input port is connected to the O2 video
output port; I2 audio input port is connected to all the audio output ports (O1, O2, O3).
View Crosspoint Size
Shows the physical crosspoint size.
Command and Response
ȩ {getsize•<layer>}
Ȩ <size>•<layer>
Parameters
Parameter Parameter description
<size> Crosspoint size <number_of_inputs>x<number_of _outputs>
<layer> Signal type of the layer
A
audio layer
V
video layer
AV
Example
ȩ
Ȩ
Ȩ
Change the Video Autoselect Mode
The autoselect mode of the video outputs can be changed.
Command and Response #autoselect
ȩ <out>=<state>;<mode>}
Ȩ <out>=<state>;<mode>
Parameters
Parameter Parameter description
<state> Showing the
Autoselect state
E
autoselect is enabled
D
autoselect is disabled
<mode> The autoselect mode
setting
F
First detect mode
L
P
Priority detect mode
The output port numbers are listed in Port Numbering section.
Example
ȩ {as_v1=E;P}
Ȩ
The Autoselect mode of audio output1 is enabled and set to Priority mode.
INFO: The Autoselect mode can be queried by typing the {as_v<out>
