UMX-TPS-TX100 series – User's Manual 74
Event Manager
The feature means that the device can sense changes on its ports and able to react
is based on users’ feedbacks. In many cases internal events (such as signal present
or HDCP active) are necessary to display but it is not easy when the device is hard
to access (e.g. built under the desk).
setup is that after a certain type of signal has been detected on I1 port, the port has to be switched to O1.
events number depends on the device what you are using actually.
Numerous new ideas and requests have been received in connection with the features and settings of the
functions implemented. The Event editor can be opened by pressing the Edit button at each Event.
There is a grey bar on the left of the Event panel in each line. If a condition and an action are set and the Event
is enabled, the bar is displayed in green.
Control menu, Event Manager tab
The Event Editor
Press the Edit button in the desired Event line to open the Event editor window.
7
1
2
4
5
6
8
3
1
Event header The name of the Event is displayed. Type the desired name and press the Set
name button. The Event can be cleared by the Clear button. Use the tick mark
2
Condition header
protocol expression (yellow colored text) can be seen. If the advanced mode
3
Condition panel
The parameters and settings are displayed below the buttons.
4
Condition counter The set condition can be tested to see the working method in the practice.
5
Delay settings The action can be scheduled to follow the condition after the set time value.
6
Action header
protocol expression (yellow colored text) can be seen. If the advanced mode
7
Action panel
parameters and settings are displayed below the buttons.
8
Action test The set action can be tested to see the working method in the practice.
