Automatic Input Selection - Example
The Concept
be switched to the TPS output. If the Blu-ray player is connected on the HDMI input, and later the MacBook
is connected on the DP input of the transmitter, it will be switched to the TPS output – independently of the
presence of other video signals.
Settings
▪ TPS output: Set the Autoselect to Enabled. Set Autoselect mode to Priority detect. The priorities are the
following (the lowest number means the highest priority):
Source device Input interface Input port Priority
MacBook DP IN I3 0
Blu-ray player HDMI IN I2 1
PC I4 2
I1 3
and the TPS Audio Output sections.
Video Interface
Video Input Modes
INFO:
Input Source Selection Modes
▪ pressing Video Select button on the device;
▪
▪
▪ using the Autoselect function.
The Autoselect Feature
There are three types of Autoselect as follows.
▪ First detect mode: selected input port is kept
connected to the output as long as it has an
active signal.
▪ Priority detect mode: always the highest
priority active input is selected to transmit.
▪ Last detect mode: always the last attached
input is selected to transmit.
New event?
„First detect” „Last detect”
No Audio/Video
transmission
Remains
selected
Last connected
input is selected
Y
„Off”
N
N
Current
Autoselect mode
„No signal”
Port with
priority 0 has a
valid signal?
Selected
port still has a
valid signal?
„Priority detect”
Port with
priority 1 has a
valid signal?
N
N
Port with
priority 30 has a
valid signal?
N
Display
Test pattern
Test
pattern generator
setting
Y
Y
Port with
priority 2 has a
valid signal?
N
Port with priority
0 is selected
Port with priority
1 is selected
Port with priority
2 is selected
Port with priority
30 is selected
Y
Y
Y
To Next Page
