UMX-TPS-TX100 series – User's Manual 3
Symbol Legend
The following symbols and markings are used in the document:
WARNING! Safety-related information which is highly
recommended to read and keep in every case!
ATTENTION! Useful information to perform a successful procedure;
it is recommended to read.
DIFFERENCE:
INFO: A notice which may contain additional information. Procedure
can be successful without reading it.
DEFINITION: The short description of a feature or a function.
TIPS AND TRICKS: Ideas which you may have not known yet but
can be useful.
Navigation Buttons
Go back to the previous page. If you clicked on a link previously,
you can go back to the source page by the button.
Navigate to the Table of Contents.
Step back one page.
Step forward to the next page.
Document Information
This User’s Manual applies to the following versions of the mentioned
About Printing
eco-friend mentality. Thus, this document is made for digital usage
primarily. If you need to print out few pages for any reason, follow the
recommended printing settings:
▪ Page size: A4
▪ Output size: Fit to page or Match page size
▪
TIPS AND TRICKS: Thanks to the size of the original page, a border
around the content (gray on the second picture below) makes
possible to organize the pages better. After punching the printed
pages, they can be placed easily into a ring folder.
Hashtag (#) Keywords in the Document
This user's manual contains keywords with hashtag (#) to help you to
The format of the keywords is the following:
#<keyword>
The usage of the keywords: use the Search
of your PDF reader application, type the # (hashtag) character and the
wished keyword.
The #new
Example
#dhcp
Programmer's reference section.
1
2
3
Item
2.8.0b2
Controller
UMX-TPS-TX120, -TX130, -TX140,
UMX-TPS-TX140K, TX140-Plus
1.5.0b4
1.4.0b8
FP-UMX-TPS-TX120, -TX130 1.4.0b8
Hardware
UMX-TPS-TX120, -TX130, -TX140,
UMX-TPS-TX140K, TX140-Plus
2.0
1.2
FP-UMX-TPS-TX120, -TX130 1.2
Document revision: v3.0
Release date: 18-05-2021
