Matrix ETERNITY ME User Manual

Matrix ETERNITY Quick Start 97
ETERNITY ME TWT8 + SLT24
L1
1
2
3
4
5
6
7
8
RJ45-1
(Blue)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
SLT 01
SLT
02
SLT
SLT
04
Connector
Color
Connection H/w Port Offset
RJ45-2
(Orange)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
SLT 05
SLT 06
SLT
SLT
08
RJ45-3
(Green)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
SLT 09
SLT
10
SLT
SLT
12
RJ45-4
(Brown)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
SLT 13
SLT 14
SLT
SLT
16
RJ45-5
(Blue)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
SLT 17
SLT 18
SLT
SLT
20
RJ45-6
(Orange)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
SLT 21
SLT
22
SLT
SLT
24
RJ45-7
(Green)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
TWT
TWT
TWT
TWT
RJ45-8
(Brown)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
TWT
TWT
TWT
TWT
01
02
04
05
06
08

Matrix ETERNITY ME Specifications

General

Brand	Matrix
Model	ETERNITY ME
Category	PBX
Language	English
