Matrix ETERNITY ME User Manual

116 Matrix ETERNITY Quick Start
ETERNITY PE Door Phone Card
Connector Pin Port Connection Color
RJ45-1 (Blue) 1 DOP-1 Relay A Orange-White
2 Relay B Orange
3 Door Phone-1 Status Green-White
4 MIC Input Blue
5 Speaker Output Blue-White
6 Analog Ground Green
7 DIP-1 DIP_B Brown-White
8DIP_ABrown
RJ45-2
(Orange)
1 DOP-2 Relay A Orange-White
2 Relay B Orange
3 Door Phone-2 Status Green-White
4 MIC Input Blue
5 Speaker Output Blue-White
6 Analog Ground Green
7 Not Connected Not Connected Brown-White
8 Not Connected Not Connected Brown
RJ45-3
(Green)
1 DOP-3 Relay A Orange-White
2 Relay B Orange
3 Door Phone-3 Status Green-White
4 MIC Input Blue
5 Speaker Output Blue-White
6 Analog Ground Green
7 Not Connected Not Connected Brown-White
8 Not Connected Not Connected Brown
