40 Matrix ETERNITY Quick Start
Installing the T1E1PRI Card
• Unpack T1E1PRI Card.
• By default, termination resistance of T1E1 port set as 120 for E1 connectivity.
• To use the T1E1 port for T1 connectivity, termination resistance should be
changed to 100.
In ETERNITY ME
• T1E1Port -1 termination resistance can be changed using DIP switch SW5.
• Set Pins of SW5 as shown below to set termination resistance.
• T1E1 Port 2 termination resistance can be changed using DIP Switch SW2.
• Set Pins of SW2 as shown below to set termination resistance.
In ETERNITY GE
• Termination resistance can be changed, using Jumper J5.
• To set the Line Termination Resistor for the PRI Port for T1 or E1 Connectivity,
you must change the position of the jumper J5. Refer the table below.
Pin-1 Pin-2 Pin-3 Pin-4 Resistance
OFF OFF ON OFF 120 (for E1)
OFF ON OFF OFF 100 (for T1)
Pin-1 Pin-2 Pin-3 Pin-4 Resistance
OFF OFF ON OFF 120 (for E1)
OFF ON OFF OFF 100 (for T1)
Jumper Position Meaning
J5 BC To set termination resistance of 120 for E1 connectivity
J5 AB To set termination resistance of 100 for T1 connectivity
