14 Matrix ETERNITY Quick Start
LED indication for E&M Ports
Stage
LED
Color
LED Cadence
Initialization
At Power ON Red
L1 to L8 glow one after the other in a
sequence, ON 100ms -OFF.
L1 ON 100ms-OFF,
L2 100ms ON-OFF,
L3 100ms ON-OFF,
L4 100ms ON-OFF……L8 100ms ON-OFF
Green
L1 to L8 glow one after the other in a
sequence, ON 100ms -OFF.
L1 ON 100ms-OFF,
L2 100ms ON-OFF,
L3 100ms ON-OFF,
L4 100ms ON-OFF……L8 100ms ON-OFF
Standby (waiting to
be detected by
Master Card)
Green,
Orange
L1 toggles Green ON 1 sec, Orange ON 1 sec
Normal (Port Event)
M-Wire High Green LED of the Port continuously ON
M-Wire Low LED of the Port continuously OFF
E-Wire High Red LED of the Port continuously ON
M-Wire Low LED of the Port continuously OFF
E-Wire and M-Wire
High
Orange LED of the Port continuously ON
Errors
Controller RAM
failure
Orange All LEDs Toggle at 1 sec
External RAM failure Orange All LEDs Toggle at 2 sec
Eprom failure Orange All LEDs Toggle at 3 sec
Invalid Slot detected Orange All LEDs Toggle at 6 sec
