Matrix ETERNITY Quick Start 45
Installing VMS Card
• Unpack VMS Card.
• Insert VMS Card into a universal slot and secure the card.
• Switch on power supply and observe the reset cycle and the LED indication of
the VMS Card.
At Power ON,
• All LEDS are OFF.
• L1 LED glows green as soon as initialization process starts. Initialization
process starts after approximately 100 seconds.
• After approximately 80 seconds of glowing of L1, LEDs will follow the sequence
as under:
• Glow Green-500ms-Glow Red-500ms-Glow Orange 500 ms-LEDs turned
OFF.
In Normal Condition, LED1 will indicate the following:
LED indication of VMS Card
3
• For configuration instructions, under Basic Configuration, see “Configuring the
VMS Card”.
• If you need to generate configuration and debug reports, connect the COM Port
of the VMS Card with that of a PC using the communication cable supplied with
the card.
Condition LED Color Cadence
Normal Green 1 sec On - 1 sec Off
File System Error Red 1sec On - 1 sec Off
Pen Drive Error-Pen Drive
Full
Red Five times 100ms On-100ms Off
(for 1 sec) - 1 sec Off
3. There is no LED on the VMS Card of ETERNITY PE.
