64 Matrix ETERNITY Quick Start
To know more about feature interactions of DID, DISA, Trunk Auto Answer, DDI and CLI Based
Routing, refer the topic “Incoming Call Management” in the System Manual.
Operator Group
• By default, all the stations and trunks are assigned Operator-1.
• By default, Routing Group number 32 is programmed as Operator-1 for working
hours, break hours and non-working hours.
• By default, members of the Routing Group 32 are DKP001, SLT 001 and SLT
002.
• Make a list of Operator stations for working hours, break hours and non-working
hours.
• Go to ‘Routing Groups’ to create routing groups with member stations which are
to be used as Operator for working hours, break hours and non-working hours.
• To assign the Routing Group you created as Operators, open ‘Operators’ page.
• To assign Operator to the stations, go to ‘Station Basic Feature Template’.
• Operator for the trunks is to be assigned in the ‘Trunk Feature Template’ of the
trunks.
T1E1PRI
• By default, the orientation type of the T1E1 port is Terminal.
• To connect the T1E1 port with the Public network, the orientation type of the
T1E1 port should be Terminal (TE).
• To connect the T1E1 port for private networking, the orientation type should be
set to Terminal/Network depending on the network scenario.
• Go to ‘Port Parameters’ under the link ‘T1E1 Configuration’ to configure the
basic attributes of the T1E1 port.
• By default, the T1E1 port is set to support “E1 PRI” signaling. Go to ‘Port
Parameters’ - ‘Signal Type’ to change the signaling as T1 PRI/E1 CAS/T1 RBS
as supported by the exchange (Network).
