8 Matrix ETERNITY Quick Start
In ETERNITY GE
• To set the BRI Ports of ETERNITY GE as NT or TE, refer the tables below to
change the position of the Jumpers on the main board of the BRI Card. Default:
all ports are set as TE.
Mode Jumper Position
BRI Port 7 BRI Port 8
J44 J45 J46 J47 J48 J49 J50 J51
NT BC BC BC BC BC BC BC BC
TE AB AB AB AB AB AB AB AB
Mode Jumper Position
BRI Port 1 BRI Port 2
J1 J2 J3 J4 J6 J7 J8 J9
NT BC BC BC BC BC BC BC BC
TE AB AB AB AB AB AB AB AB
Mode Jumper Position
BRI Port 3 BRI Port 4
J10 J16 J17 J18 J14 J15 J19 J20
NT BC BC BC BC BC BC BC BC
TE AB AB AB AB AB AB AB AB
