20 Matrix ETERNITY Quick Start
• The ETERNITY ME and GE VoIP Cards have two LEDs:
• LED 1 indicates the status of the VoIP card.
• LED 2 indicates the status of any of the SIP Trunks to which this LED is
assigned.
• There are no LEDs the VoIP card of ETERNITY PE.
• Described below are the LED indication of LED 1 and LED 2 of the VoIP card of
ETERNITY ME and GE.
LED 1 - VoIP Card Status Indication
VoIP Card status LED Color Cadence
Booting Up (Power On) Green Continuous On
Once Stack Construct
COMMAND is received from
Master, LED will remain ON Red
and wait for the WAN and DSP
download response.
Red Continuous On
WAN Stack Construction Failed -
(PPPoE connection is not
established or IP Address Invalid
or DHCP Client does not retrieve
network parameters or any other
reason)
Red
On 1 sec-Off 1 sec
On 1 sec-Off 1 sec
LAN Stack constructed or not
DSP Image is downloaded
successfully or not
WAN Stack constructed
successfully
Red
On 500msec-Off 3500 msec
LAN Stack constructed or not
DSP Image is not downloaded
successfully (in all DSPs)
WAN Stack constructed
successfully
Green
On 500msec-Off 3500 msec
LAN Stack constructed
successfully
DSP Image not downloaded
successfully (in any DSP but not
all)
