Matrix ETERNITY ME User Manual

42 Matrix ETERNITY Quick Start
1. Port Active Mode
Signaling Type: E1-PRI
LED1/LED3 Pattern:
LED2/LED4 Pattern:
Signaling Type: E1-CAS
LED1/LED3 Pattern:
LED2/LED4 Pattern:
Port Status Color Cadence
Layer 1 established successfully GREEN Continuous ON
CRC4 Alarm GREEN 100ms ON-100 ms OFF
BFA Alarm RED 500ms ON-500 ms OFF
LOS Alarm RED Continuous ON
Port Status Color Cadence
Layer 1 established successfully GREEN Continuous ON
RAI Alarm RED 500ms ON-500 ms OFF
AIS or LOS Alarm RED Continuous ON
Port Status Color Cadence
Layer 1 established successfully GREEN Continuous ON
CRC4 Alarm GREEN 100ms ON-100 ms OFF
MFA Alarm RED 100ms ON-100 ms OFF
BFA Alarm RED 500ms ON-500 ms OFF
LOS Alarm RED Continuous ON
Port Status Color Cadence
Layer 1 established successfully GREEN Continuous ON
Y-Bit Alarm GREEN 100ms ON-100 ms OFF
