ETERNITY GE E&M4
Cable Diagram for cards of ETERNITY-PE
ETERNITY PE SLT8
L1 L2
1
2
3
4
RJ45-1
RJ45-3
1Open Gray 03
2 SB3 Green-White
3M1 OUT Green
4 RX3 SPCH A Orange-White
5 SPCH3 A Blue
6 SPCH3 B Blue-White
7 RX3 SPCH B Orange
8 E3 IN Brown-White
9BGND Brown
10 CCC3 Gray-White
Pin Connection Colour H/w Port
No. Offset
1Open Gray 01
2 SB1 Green-White
3M1 OUT Green
4 RX1 SPCH A Orange-White
5 SPCH1 A Blue
6 SPCH1 B Blue-White
7 RX1 SPCH B Orange
8 E1 IN Brown-White
9BGND Brown
10 CCC1 Gray-White
Pin Connection Colour H/w Port
No. Offset
RJ45-2
RJ45-4
1Open Gray 02
2 SB2 Green-White
3M2 OUT Green
4 RX2 SPCH A Orange-White
5SPCH2 A Blue
6 SPCH2 B Blue-White
7 RX2 SPCH B Orange
8 E2 IN Brown-White
9BGND Brown
10 CCC2 Gray-White
Pin Connection Colour H/w Port
No. Offset
1Open Gray 04
2 SB4 Green-White
3M4 OUT Green
4 RX4 SPCH A Orange-White
5SPCH4 A Blue
6 SPCH4 B Blue-White
7 RX4 SPCH B Orange
8 E4 IN Brown-White
9BGND Brown
10 CCC4 Gray-White
Pin Connection Colour H/w Port
No. Offset
RJ45-1 Blue - (Blue & White)
Orange - (Orange & White)
Brown - (Brown & White)
RJ45-2
(Orange)
RJ45-3
(Green)
(Blue) SLT 02
Green - (Green & White) SLT 03
SLT 04
Blue - (Blue & White) SLT 05
Orange - (Orange & White) SLT 06
Blue - (Blue & White) SLT 07
Orange - (Orange & White) SLT 08
SLT 01
Connector Color Connection H/w port Offset
