536
Controls in detail
Useful features
Ashtrays
Center console ashtray
1 Button for disengaging ashtray
2 Cover plate
Opening ashtray
왘 Press mark on cover plate 2 forward.
Removing ashtray insert
왘 Push sliding button 1 to the left.
The ashtray is disengaged and slides
out a short way.
왘 Remove the insert from the ashtray
frame.
Reinstalling ashtray insert
왘 Install the insert by pushing it back into
the frame until it engages.
Closing ashtray
왘 Briefly press mark on cover plate 2
forward.
Rear door ashtray
Opening ashtray
왘 Lift up the cover.
Removing ashtray insert
1 Insert
왘 Press the open cover outwards beyond
the stop.
Ashtray insert 1 pops out of the hold-
er.
왘 Remove insert by pulling it upward.
Reinstalling ashtray insert
왘 Install the insert by pushing it back into
the frame until it engages.
Warning! G
Remove ashtray only with vehicle standing
still. Engage the electronic parking brake to
secure vehicle from movement. Set auto-
matic transmission to park position P. With
the automatic transmission set to park
position P, turn off the engine.
