M800S/M80/E80 Series Connection and Setup Manual
4 General Specifications
192
IB-1501269-J
4.21.2 SD Interface (Memory I/F card)
(Note) SDXC is not supported.
(1) Precautions for use of commercially available SD card
MITUBISHI will not provide performance guarantee and maintenance for commercially available SD card, mini SD
card or micro SD card (requires converting adapter). In case of using one of them, careful performance check must
be required by the machine tool builder.
Commercially available devices may not be compatible with MITSUBISHI units or suitable FA environment for
temperature- or noise-wise.
(2) Precautions for insertion/removal of SD card
When inserting/removing an SD card, turn the MITUBISHI device's power OFF. Do not pull out the card or turn OFF
the power during access to the SD card. Failure to observe this could cause the memory contents to be erased.
In case of emergency, always perform backups by having your important data duplicate, etc. as MITUBISHI will not
guarantee the broken or lost data.
4.21.3 LAN Interface (Control Unit)
(Note 1) Data transfer speed is the theoretical value on the standard, and the actual speed will be inferior to the value
listed above. The transfer speed may be restrained depending on the specification of the connected device.
(Note 2) When using half-duplex communication, the response time may become long depending on the connected
device.
Use full-duplex communication to connect with the opposite device via a switching HUB.
(1) Precautions for selection of LAN cable
Make sure to select the LAN cables which are "category 5e or above" and "shielded". Cable wire material with
double shielded, which is appropriate for FA environment., is recommended.
M800S / M80
Standards SD/SDHC (Note)
Transfer speed According to the connecting SD card
Capacity 32GB
Number of free ports Front X 1, Rear X 1
M800S/M80
Standards 100BASE-TX / 10BASE-T
Data transfer speed
(Note 1)
100Mbps / 10Mbps
Number of free ports Control unit × 2
