M800S/M80/E80 Series Connection and Setup Manual
19 Setting the Parameters and Date/Time
420
IB-1501269-J
Refer to the section of "Alarm/Parameter Manual" for the details of the parameters.
You can also refer to the parameter guidance display.
Normally, the initial setting of NC is performed with NC Configrator2.
NC Configurator2 is a tool for supporting the parameter setting of NC.
For the details, refer to "NC Configurator2 Instruction Manual"(IB-1501046).
19.1 Selecting the NC System Type and Displayed Language
When employing the lathe system, set the parameter as follows.
(1) On the Mainte screen, select [Mainte] and then [Psswd input].
Enter the machine parameter password in the setting area and press the [INPUT] key.
(Note 1) To enter the character "A", press the shift key and then "A" key. Do not press both keys at the same time.
(Note 2) The entered password is displayed as "*****".
(2) Go back to the Mainte screen and select [Param].
(3) Select [Para Nosearch]. Enter "1043" in the setting area and press the [INPUT] key.
Select the language to be displayed.
(4) Select [Para Nosearch]. Enter "1007" in the setting area and press the [INPUT] key.
The screen changes to the base system parameters screen. The cursor moves to the "#1007 System type select"
field.
(5) Enter "1" in the setting area and press the [INPUT] key. (0: Machining center system 1: Lathe system)
(6) Turn the power OFF and ON.
WARNING
Confirm the emergency stop state before carrying out the steps in this chapter.
To Next Page
