M800S/M80/E80 Series Connection and Setup Manual
3 List of Configuration
21
IB-1501269-J
3.12 Remote I/O Unit [E80]
(Note) DI: Digital input signals, DO: Digital output signals, AI: Analog input signals, AO: Analog output signals
3.13 Function Expansion Unit [M80]
3.14 Communication Expansion Unit
(Note) To use the communication expansion unit, the option relay unit (FCU8-EX70x) is required.
Classification Type Components Remarks
DI 24V/0V common input [32 points]
DO Source output [32 points]
FCU8-DX220
Base card
RIO 2.0 connector set
DI: 32-points 24V/0V common type
Do: 32-points source type (200mA/point)
Number of occupied stations: 1
DI 24V/0V common input [64 points]
DO Source output [48 points]
FCU8-DX230
Base card
RIO 2.0 connector set
DI: 64-points 24V/0V common type
DO: 48-points source type (200mA/point)
Number of occupied stations: 2
DI 24V/0V common input
DO Source output [48 points]
AO Analog output [1 point]
FCU8-DX231
Base card
RIO 2.0 connector set
DI: 64-points 24V/0V common type
DO: 48-points source type (200mA/point)
AO: 1 point
Number of occupied stations: 2
AI Analog input [4 points]
AO Analog output [1 point]
FCU8-DX202
Base card
RIO 2.0 connector set
AI : 4 points
AO: 1 point
Number of occupied stations: 1
DI 0V common input [16 points]
DO Source output (large capacity) [8
points]
FCU8-DX213
Base card
RIO 2.0 connector set
DI: 16-points 0V common type (3mA/point)
DO: 8-points source type (2A/point)
Number of occupied stations: 1
DI 0V common input [16 points]
DO Source output (large capacity) [8
points]
FCU8-DX213-1
Base card
RIO 2.0 connector set
DI: 16-points 0V common type (9mA/point)
DO: 8-points source type (2A/point)
Number of occupied stations: 1
Thermistor input [12 points] FCU8-DX408
Base card
RIO 2.0 connector set
Thermistor input: 12 points
Number of occupied stations: 3
Multi-analog input [4 points] (Note 3) FCU8-DX409
Base card
RIO 2.0 connector set
Multi-analog input: 4 points
(Note 3) Select voltage input, current input,
thermocouple and resistance temperature
detector input for each ch.
Number of occupied stations: 4
Classification Type Components Remarks
Functional safety expansion unit FCU8-EX133 Add-on card Smart safety observation
Classification Type Components Remarks
CC-Link expansion unit FCU8-EX561 CC-Link I/F PCB CC-Link 1ch
PROFIBUS-DP master unit FCU8-EX563 PROFIBUS-DP I/F PCB PROFIBUS-DP 1ch
CC-Link IE Field
Master/local unit
FCU8-EX564
Base card
Add-on card
CC-Link IE Field 2ch
EtherNet/IP
Scanner/adapter unit
FCU8-EX565
Base card
Add-on card
EtherNet/IP 1ch
(Only LAN1, LAN2 cannot be used)
FL-net expansion unit FCU8-EX568
Base card
Add-on card
FL-net 1ch
(Only LAN1, LAN2 cannot be used)
Classification Type Components Remarks
Option Relay Unit FCU8-EX702 Relay PCB For communication expansion unit 1 slot
Option Relay Unit FCU8-EX703 Relay PCB For communication expansion unit 2 slots
