Mitsubishi M800S series User Manual

M800S/M80/E80 Series Connection and Setup Manual
9 Connection of Operation Panel I/O Unit
280
IB-1501269-J
9.8.5 Connection with the scan input signal (FCU8-DX834)
For connection details, refer to the descriptions on machine output connector pin assignment in "(19) OPKB (Scan input,
Scan output)" of "General Specifications: Operation Panel I/O Unit".
KYC0*
X240
KYC1*
KYC2*
KYC3*
KYC4*
KYC5*
KYC6*
KYC7*
X241
KYD0*
X242X243X244X245X246X247
X248X249
KYD1*
KYD2*
KYD3*
KYD4*
KYD5*
KYD6*
KYD7*
A2
B2
A3
B3
A4
B4
A5
B5
A6
B6
A7
B7
A8
B8
A9
B9
OPKB
X24AX24BX24CX24DX24EX24F
X250X251X252X253X254X255X256X257
X258X259X25AX25BX25CX25DX25EX25F
X260X261X262X263X264X265X266X267
X268X269X26AX26BX26CX26DX26EX26F
X270X271X272X273X274X275X276X277
X278X279X27AX27BX27CX27DX27EX27F
FCU8-DX834
Machine side
