M800S/M80/E80 Series Connection and Setup Manual
15 Cable
347
IB-1501269-J
15.2.6 J010 Cable
Max. cable length: 1m
Application: Operation panel I/O interface cable
(Note) Use the wire material of which impedance characteristics is 110Ω.
15.2.7 J012 Cable
Max. cable length: 1m
Application: Operation panel I/O interface cable (for FCU8-DX834)
(Note) Use the wire material of which impedance characteristics is 110Ω.
[CJ71]
Connector : 2-1318119-4
Contact : 1318107-1
Recommended manufacturer :
Tyco Electronics
Wire material : HRZEV-SB-A(20276) AWG22×3P
Recommended manufacturer : DYDEN
[CJ71]
Connector : 2-1318119-4
Contact : 1318107-1 (1318105-1)
Recommended manufacturer :
Tyco Electronics
Wire material : HK-SB/20276XL Black LF 2P×22AWG
Recommended manufacturer : Taiyo Cabletec
[RIO]
Connector : 1-1318119-3
Contact : 1318107-1
Recommended manufacturer :
Tyco Electronics
CJ71 CJ71
AWG22×3P
TXRXD*
TXRXD
5V
3.3V
0V
0V
TXRXD*
TXRXD
5V
3.3V
0V
0V
CJ71
1A
3B
1B
2A
2B
4B
1A
3B
1B
2A
2B
4B
CJ71
4A 4A
FG FG
Drain wire
(With shield / drain wire)
Drain wire
CJ71 RIO
J012 L**.*M
CJ71
1A
3B
1BTXRXD*
TXRXD
2A5V
3.3V 2B
0V
4BNC
TXRXD*
TXRXD
0V
1A
3B
1B
2A
2B
RIO
4AFG FG
3A
3A
N.C.
N.C.
N.C.
Drain wire
Drain wire
