M800S/M80/E80 Series Connection and Setup Manual
17 Setting the Hardware
403
IB-1501269-J
17.6.4.1 Fixed Device Assignment
(1) By setting the parameter "#53001 RIO dev assign" to "0", the PLC device assignment method, which is to be used
for input/output of each remote I/O unit station, will be the fixed device assignment.
(2) PLC devices assigned for each remote I/O unit station at the time of the fixed device assignment are as follows:
(Note) Do not use the input/output signals of the system-occupied stations of RIO3 and operation panel I/O unit-
connected channels.
(3) A part of PLC devices assigned for each station of remote I/O units can input/output signals with PLC high speed by
setting the high-speed input/output specification parameters or R registers.
(a) The devices for inputting/outputting signals with PLC high speed can be set individually for the high-order and
the low-order per 16 points for DI and DO of each remote I/O unit station.
(b) Only devices of the first to eighth stations for each remote I/O channel can input/output signals with PLC high
speed. The devices of the ninth to 64th stations input/output with PLC medium speed.
(c) The parameter and R register numbers for the high-speed input/output designation are as follows:
(Note 1) The above parameters are invalid when the devices have been assigned arbitrarily.
(Note 2) Refer to "PLC Programming Manual" for details of the setting method.
Station No.
Channel No. 1 2 … 8 9 … 63 64
RIO1
Input device
X0000
to X001F
X0020
to X003F
…
X00E0
to X00FF
ZR5000
/ ZR5001
…
ZR5108
/ ZR5109
ZR5110
/ ZR5111
Output device
Y0000
to Y001F
Y0020
to Y003F
…
Y00E0
to Y00FF
ZR6000
/ ZR6001
…
ZR6108
/ ZR6109
ZR6110
/ ZR6111
RIO2
Input device
X0100
to X011F
X0120
to X013F
…
X01E0
to X01FF
ZR5200
/ ZR5201
…
ZR5308
/ ZR5309
ZR5310
/ ZR5311
Output device
Y0100
to Y011F
Y0120
to Y013F
…
Y01E0
to Y01FF
ZR6200
/ ZR6201
…
ZR6308
/ZR6309
ZR6310
/ ZR6311
RIO3
Input device
X0200
to X021F
X0220
to X023F
…
X02E0
to X02FF
ZR5400
/ ZR5401
…
ZR5508
/ ZR5509
ZR5510
/ ZR5511
Output device
Y0200
to Y021F
Y0220
to Y023F
…
Y02E0
to Y02FF
ZR6400
/ ZR6401
…
ZR6508
/ ZR6509
ZR6510
/ ZR6511
Station No.
Channel No.
1 to 4 5 to 8
Parameter No. R register No. Parameter No. R register No.
RIO1
High-speed input
specification
＃ 6457
R782
8 low-order
＃ 6458
R7828 high-order
High-speed output
specification
＃ 6461
R7830 low-order
＃ 6462
R7830 high-order
RIO2
High-speed input
specification
＃ 6459
R7829 low-order
＃ 6460
R7829 high-order
High-speed output
specification
＃ 6463
R7831 low-order
＃ 6464
R7831 high-order
RIO3
High-speed input
specification
＃ 6465
R7832 low-order
＃ 6466
R7832 high-order
High-speed output
specification
＃ 6473
R7836 low-order
＃ 6474
R7836 high-order
