10 Connection of Remote I/O Unit
305
IB-1501269-J
10.8 Connecting with Safety Machine Control Signal (FCU8-DX651)
[Safety DI input]
CAUTION
1. Connect the cable to the designated connector. Incorrect connections could damage the device.
2. Do not connect or disconnect the connection cables between each unit while the power is ON.
SX00A
SX00B
COM+
COM+
SX01A
SX01B
COM+
COM+
SX02A
SX02B
COM+
COM+
SX03A
SX03B
COM+
COM+
SX04A
SX04B
COM+
COM+
SX05A
SX05B
COM+
COM+
SX06A
SX06B
COM+
COM+
SX07A
SX07B
COM+
COM+
SDI1
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A1
A2
A3
A4
A5
A6
B1
B2
B3
B4
B5
B6
B7
B8
B9
B10
B1
B2
B3
B4
B5
B6
FCU8-DX651
1
2
3
DCIN
+24V
0V
FG
SDI2
1
2
3
DCOUT
0V
FG
24VDC(+)
Stabilized
power supply
Machine side
