Motorola MC68HC908AB32 User Manual

System Integration Module (SIM)
Reset and System Initialization
MC68HC908AB32 — Rev. 1.0 Technical Data
MOTOROLA System Integration Module (SIM) 113
8.3.1 Bus Timing
In user mode, the internal bus frequency is either the crystal oscillator
output (CGMXCLK) divided by four or the PLL output (CGMVCLK)
divided by four. See Section 9. Clock Generator Module (CGM).
8.3.2 Clock Start-Up from POR or LVI Reset
When the power-on reset module or the low-voltage inhibit module
generates a reset, the clocks to the CPU and peripherals are inactive
and held in an inactive phase until after the 4096 CGMXCLK cycle POR
timeout has been completed. The RST
pin is driven low by the SIM
during this entire period. The IBUS clocks start upon completion of the
timeout.
8.3.3 Clocks in Stop and Wait Modes
Upon exit from stop mode (by an interrupt, break, or reset), the SIM
allows CGMXCLK to clock the SIM counter. The CPU and peripheral
clocks do not become active until after the stop delay timeout. This
timeout is selectable as 4096 or 32 CGMXCLK cycles. (See 8.7.2 Stop
Mode.)
In wait mode, the CPU clocks are inactive. The SIM also produces two
sets of clocks for other modules. Refer to the wait mode subsection of
each module to see if the module is active or inactive in wait mode.
Some modules can be programmed to be active in wait mode.
8.4 Reset and System Initialization
The MCU has the following reset sources:
• Power-on reset module (POR)
• External reset pin (RST
)
• Computer operating properly module (COP)
• Low-voltage inhibit module (LVI)
• Illegal opcode
• Illegal address
