Serial Peripheral Interface Module (SPI)
I/O Signals
MC68HC908AB32 — Rev. 1.0 Technical Data
MOTOROLA Serial Peripheral Interface Module (SPI) 301
The SPI has limited inter-integrated circuit (I
2
C) capability (requiring
software support) as a master in a single-master environment. To
communicate with I
2
C peripherals, MOSI becomes an open-drain output
when the SPWOM bit in the SPI control register is set. In I
2
C
communication, the MOSI and MISO pins are connected to a
bidirectional pin from the I
2
C peripheral and through a pullup resistor to
V
DD
.
16.13.1 MISO (Master In/Slave Out)
MISO is one of the two SPI module pins that transmits serial data. In full
duplex operation, the MISO pin of the master SPI module is connected
to the MISO pin of the slave SPI module. The master SPI simultaneously
receives data on its MISO pin and transmits data from its MOSI pin.
Slave output data on the MISO pin is enabled only when the SPI is
configured as a slave. The SPI is configured as a slave when its
SPMSTR bit is logic 0 and its SS
pin is at logic 0. To support a multiple-
slave system, a logic 1 on the SS
pin puts the MISO pin in a high-
impedance state.
When enabled, the SPI controls data direction of the MISO pin
regardless of the state of the data direction register of the shared I/O
port.
16.13.2 MOSI (Master Out/Slave In)
MOSI is one of the two SPI module pins that transmits serial data. In full-
duplex operation, the MOSI pin of the master SPI module is connected
to the MOSI pin of the slave SPI module. The master SPI simultaneously
transmits data from its MOSI pin and receives data on its MISO pin.
When enabled, the SPI controls data direction of the MOSI pin
regardless of the state of the data direction register of the shared I/O
port.
