Motorola MC68HC908AB32 User Manual

Serial Peripheral Interface Module (SPI)
I/O Signals
MC68HC908AB32 — Rev. 1.0 Technical Data
MOTOROLA Serial Peripheral Interface Module (SPI) 303
When an SPI is configured as a master, the SS input can be used in
conjunction with the MODF flag to prevent multiple masters from driving
MOSI and SPSCK. (See 16.8.2 Mode Fault Error.) For the state of the
SS
pin to set the MODF flag, the MODFEN bit in the SPSCK register
must be set. If the MODFEN bit is low for an SPI master, the SS
pin can
be used as a general-purpose I/O under the control of the data direction
register of the shared I/O port. With MODFEN high, it is an input-only pin
to the SPI regardless of the state of the data direction register of the
shared I/O port.
The CPU can always read the state of the SS
pin by configuring the
appropriate pin as an input and reading the port data register. (See
Table 16-3.)
16.13.5 CGND (Clock Ground)
CGND is the ground return for the serial clock pin, SPSCK, and the
ground for the port output buffers. It is internally connected to V
SS
as
shown in Table 16-1.
Table 16-3. SPI Configuration
SPE SPMSTR MODFEN SPI Configuration State of SS Logic
0
X
(1)
X Not enabled
General-purpose I/O;
SS ignored by SPI
1 0 X Slave Input-only to SPI
1 1 0 Master without MODF
General-purpose I/O;
SS ignored by SPI
1 1 1 Master with MODF Input-only to SPI
Note 1. X = Don’t care
