System Integration Module (SIM)
Technical Data MC68HC908AB32 — Rev. 1.0
122 System Integration Module (SIM) MOTOROLA
Table 8-3. Vector Addresses
Vector Priority Address Vector
Lowest
$FFD0 ADC Conversion Complete Vector (High)
$FFD1 ADC Conversion Complete Vector (Low)
$FFD2 Keyboard Vector (High)
$FFD3 Keyboard Vector (Low)
$FFD4 SCI Transmit Vector (High)
$FFD5 SCI Transmit Vector (Low)
$FFD6 SCI Receive Vector (High)
$FFD7 SCI Receive Vector (Low)
$FFD8 SCI Error Vector (High)
$FFD9 SCI Error Vector (Low)
$FFDA Reserved
$FFDB Reserved
$FFDC Reserved
$FFDD Reserved
$FFDE Timer B Channel 3 Vector (High)
$FFDF Timer B Channel 3 Vector (Low)
$FFE0 Timer B Channel 2 Vector (High)
$FFE1 Timer B Channel 2 Vector (Low)
$FFE2 SPI Transmit Vector (High)
$FFE3 SPI Transmit Vector (Low)
$FFE4 SPI Receive Vector (High)
$FFE5 SPI Receive Vector (Low)
$FFE6 Timer B Overflow Vector (High)
$FFE7 Timer B Overflow Vector (Low)
$FFE8 Timer B Channel 1 Vector (High)
$FFE9 Timer B Channel 1 Vector (Low)
$FFEA Timer B Channel 0 Vector (High)
$FFEB Timer B Channel 0 Vector (Low)
$FFEC Timer A Overflow Vector (High)
$FFED Timer A Overflow Vector (Low)
$FFEE Timer A Channel 3 Vector (High)
$FFEF Timer A Channel 3 Vector (Low)
$FFF0 Timer A Channel 2 Vector (High)
$FFF1 Timer A Channel 2 Vector (Low)
$FFF2 Timer A Channel 1 Vector (High)
$FFF3 Timer A Channel 1 Vector (Low)
$FFF4 Timer A Channel 0 Vector (High)
$FFF5 Timer A Channel 0 Vector (Low)
$FFF6 Programmable Interrupt Timer (High)
$FFF7 Programmable Interrupt Timer (Low)
$FFF8 PLL Vector (High)
$FFF9 PLL Vector (Low)
$FFFA IRQ Vector (High)
$FFFB IRQ Vector (Low)
$FFFC SWI Vector (High)
$FFFD SWI Vector (Low)
Highest
$FFFE Reset Vector (High)
$FFFF Reset Vector (Low)
