Central Processor Unit (CPU)
CPU Registers
MC68HC908AB32 — Rev. 1.0 Technical Data
MOTOROLA Central Processor Unit (CPU) 93
NOTE: The location of the stack is arbitrary and may be relocated anywhere in
RAM. Moving the SP out of page 0 ($0000 to $00FF) frees direct
address (page 0) space. For correct operation, the stack pointer must
point only to RAM locations.
7.4.4 Program Counter
The program counter is a 16-bit register that contains the address of the
next instruction or operand to be fetched.
Normally, the program counter automatically increments to the next
sequential memory location every time an instruction or operand is
fetched. Jump, branch, and interrupt operations load the program
counter with an address other than that of the next sequential location.
During reset, the program counter is loaded with the reset vector
address located at $FFFE and $FFFF. The vector address is the
address of the first instruction to be executed after exiting the reset state.
7.4.5 Condition Code Register
The 8-bit condition code register contains the interrupt mask and five
flags that indicate the results of the instruction just executed. Bits 6 and
Bit
15
1413121110987654321
Bit
0
Read:
Write:
Reset: 0000000011111111
Figure 7-4. Stack Pointer (SP)
Bit
15
1413121110987654321
Bit
0
Read:
Write:
Reset: Loaded with Vector from $FFFE and $FFFF
Figure 7-5. Program Counter (PC)
