Serial Communications Interface Module (SCI)
Functional Description
MC68HC908AB32 — Rev. 1.0 Technical Data
MOTOROLA Serial Communications Interface Module (SCI) 253
To verify the start bit and to detect noise, data recovery logic takes
samples at RT3, RT5, and RT7. Table 15-2 summarizes the results of
the start bit verification samples.
Start bit verification is not successful if any two of the three verification
samples are logic 1s. If start bit verification is not successful, the RT
clock is reset and a new search for a start bit begins.
To determine the value of a data bit and to detect noise, recovery logic
takes samples at RT8, RT9, and RT10. Table 15-3 summarizes the
results of the data bit samples.
Table 15-2. Start Bit Verification
RT3, RT5, and RT7
Samples
Start Bit
Verification
Noise Flag
000 Yes 0
001 Yes 1
010 Yes 1
011 No 0
100 Yes 1
101 No 0
110 No 0
111 No 0
Table 15-3. Data Bit Recovery
RT8, RT9, and RT10
Samples
Data Bit
Determination
Noise Flag
000 0 0
001 0 1
010 0 1
011 1 1
100 0 1
101 1 1
110 1 1
111 1 0
