Checking the Resistance of the Tank, Grid, and Manifold Heaters (contd)

Table 6-8 Heater Resistance

Model Grid Marking

Grid Heater Cold Resistance

(See Note A)

7 kg/hr Model

1/3 Ø AC 200-240V 50/60 HZ

1/3 Ø N/PE AC 400/230V 50/60 HZ

700W, 230V 68 – 79 ohms

7 kg/hr Model

3 Ø AC 480V 50/60 HZ

3 Ø AC 400V 50/60HZ

700W, 400/480V 273 – 316 ohms

14 kg/hr Model

1/3 Ø AC 200-240V 50/60 HZ

1/3 Ø N/PE AC 400/230V 50/60 HZ

1200W, 230V 40 – 46 ohms

14 kg/hr Model

3 Ø AC 480V 50/60 HZ

3 Ø AC 400V 50/60HZ

1200W, 400/480V 159 – 184 ohms

NOTE A: Resistance across two heaters wired in series.

Table 6 -9 Manifold Heater Cold Resistance

Manifold Heater Cold Resistance

230V, 1000W 48 – 55 ohms

230V, 2500W 19 – 22 ohms

480V, 1190W 175 – 203 ohms

480V, 2500W 83 – 96 ohms

Table6-10TankHeaterColdResistance

Model

Tank Marking

Cold Resistance

4kgTank 230V, 1000W 48 – 55 ohms

4kgTank 480V, 1190W 175–203ohms

7kgTank 230V, 1200W 40 – 46 ohms

7kgTank 480V, 1700W 122–142ohms

10 kg Tank 230V, 1200W 40 – 46 ohms

10 kg Tank 480V, 1700W 122–142ohms
