Parts
8-20
Part 1128350_02
E 2020 Nordson Corporation
Manifold Modules
See Figures 8-12 and 8-13.
Item Part
Description Quantity Kit P/N
— — MODULE,MANIFOLD,CENTER
301 — S MANIFOLD ASSEMBLY,CENTER 1 1128158
1 ------ SS MANIFOLD,CENTER 1
2 ------ SS VALVE ASSY,PRESSURE DISCHARGE 1 1028308
3 973583 SS PLUG,O RING,STR THD,1 5/16-12 2
4 1127054 SS SPOOL,ISOLATION VALVE 1
5 940141 SS O RING,VITON,.489ID X .070W,BR,10414 1
6 986702 SS RETAINING RING,INT,100,BASIC 1
7 973537 SS PLUG,O RING,STR THD,3/8-24,STL 2
8 982178 SS SCR,SKT,M5X50,BL 3
9 983035 SS WASHER,FLT,M,REG,M5,STL,ZN 3
10 985135 SS PIN,ROLL, .250X .500,STL,ZN 2
11 ------
SS LUBRICANT,NEVER-SEEZ,NSF-H1,FOOD
GRADE
0
302 1610583 S SCR,HEX,FLANGE,M6X35,ZN 2
303 1127055 S INSULATOR,PUMP FRAME 1
304 1127060 S PAN PUMP 1
305 1127189 S SCR SKT,M8X90 SS 3
306
------ S MANIFOLD INSULATION
1
------ SS INSULATION, MANIFOLD 1128328
------ SS INSULATION, MANIFOLD, SEWN 1128329
307 ------ S LUBRICANT,NEVER-SEEZ,NSF-H1,FOOD GRADE 0
To Next Page
