Nordson ProBlue Flex User Manual

SP Pump Diagnostics and Repair
B-24
Part 1128350_02
E 2020 Nordson Corporation
Low Viscosity Double Acting Pump Assembly Parts List
SeeFigureB-7.
Item Part Description Quantity
------ ------ PUMP,LOW VISCOSITY,D/A
1 1127179 SCR,HEX,CAP,M6X110,ZN,CLASS 8.8 4
2 982135 SCR,HEX,CAP,M6X30,ZN 1
3 983410 WASHER,FLT,M,NARROW,M6,STL,ZN 5
4 163039 CUP,PISTON,SP 2
5 983445 WASHER,PISTON SEAL,SP 1
6 983446 WASHER,PISTON CUP,SP 2
7 273139 SEAL,PUMP 1
8 1128590 CYLINDER,AIR,PUMP,STD D/A,PB FLEX 1
9 155079 FORK,MAGNETIC,ASSY 1
10 503696 CAGE,BALL,SIPHON 1
11 900001 BALL,440SSTL,.500, 50 1
12 1128655 PISTON ASSY,HYD,LV,PB FLEX 1
13 940332 O RING,VITON, 2.000X2.125X.063 2
14 941332 O RING,VITON,BLK,1.812X2.000 1
15 1127239 ORING,VITON,1.609x1.887x139,-223 1
16 941290 O RING,VITON,BLK,1.562X1.750 1
17 940211 O RING,VITON, .938X1.063X.063-021 1
18 952100 CUP,U,VITON 1
19 986331 RETAINING RING,INT,100,PUSHON 1
20 1064157 NUT,HEX,LOCK,TORQUE,M6X1, DIN 980V,V3 1
21 1127042 BODY,PUMP,STD D/A 1
22 503695 SEAT,BALL,SIPHON 1
23 1127056 RETAINER,PUMP BODY,STD D/A 1
24 1126357 LOCKNUT,BEARING,PN-05,STEEL,ZINC PLTG 1
25 1127038 FRAME,PUMP,STD D/A,MACHINED 1
26 274523 HEAD, AIR CYLINDER 1
27 1128330 ACTUATOR ASSEMBLY,PUMP 1
28 982298 SCR,HEX,CAP,M5X50,BL 2
29 983408 WASHER,FLT,M,NARROW,M5,STL,ZN 2
30 940111 O RING,VITON,.301ID X .070W,BR, 10411 SB 4
31 1108372 LUBRICANT,O-RING,NSF-H1,FOOD GRADE,4L 1
32 1108371 LUBRICANT,NEVER-SEEZ,NSF-H1,FOOD GRADE 1
