Basic Melter Operation
4-9
Part 1128350_02
E 2020 Nordson Corporation
SeeFigure4-4forthelocationofthenavigationcontrols:
Item Component Type Function
1 Home Navigates to the top of the Home screen menus.
Allows access to the menu screens.
2 Clear/Reset Acknowledges, closes and resets the Temperature,
Pressure and Fill Alert, Fault and Stop conditions.
3 Help Allows access to the context sensitive help system.
4 User Control/Arrow
keys
S Accepts a user selection or input.
S Selects an option from a list.
S TogglesanoptionOnorOff.
Navigates to the next menu.
The
> appearsontherightsidewhenanadditional
menu option is available
.
Navigates to the previous menu.
Move up to the previous selection in a list.
Move down to the next selection in a list.
