Appendix A Centronics Parallel Interface
43984801TH Rev.1
136 /
Oki Data CONFIDENTIAL
Appendix A Centronics Parallel Interface
(1) Connector
• Printer side : 36 Pole Receptacle (Female)
Equivalent to 57RE-40360-730B-D29A Model (DDK Ltd.)
• Cable side: 36 Pole Plug (Male)
Equivalent to 57FE-30360-20N(D8) Model (DDK Ltd.)
(2) Cable
Cables compatible with IEEE Std 1284-1994 under 1.8mm (or equivalent product) should be used.
(It is recommended to use twisted pair cable with shield for noise control.)
Note! The cable is not included in the printer. Moreover, you can not purchase it from the Oki Data
C
orporation.
