Appendix C Maintenance Manual for Second Tray unit
43984801TH Rev.1
148 /
Oki Data CONFIDENTIAL
3.2 Arrangement of Parts
　
The arrangement of main parts is as shown in the following figure.
Figure 3-1
Connector(9715S-08Z02-G4C)
Guard-Connector
Gear-Assy-Clatch
Roller-Feed-Now
Roller-Pick-Up
Roller-Feed
A
A
Cassette-Assy
Frame-Assy-Retard
Spring-Retard
Board-OT7
CONN Cord-AMP8P-AHP8P
