1. CONFIGURATION
1. CONFIGURATION
1.1 System Configuration
As the diagram 1.1 shows, for the standard configuration printer is configured by controller unit and
engine unit.
Operator panel board
LCD:1, LED:2, SW:1(B410d/B410dn)
LCD:1, LED:2, SW:6
(B420dn/B430d/B430dn)
LED head
CENTRONICS
Main print circuit board
USB 2.0
LAN
(10BASE-T/100BASE-TX)
Toner cartridge
Image drum cartridge
High voltage power supply uint
Low voltage power supply unit
Fuser unit
Main DC Motor
2nd tray unit*
Hopping clutch (1st)
Register clutch
Hopping clutch (MPT)
Solenoid for paper inverting
Cassette & Duplex detecting
Paper end sensor
Exit sensor
Rear cover open sensor
Halogen lamp
FUSE
Temperature sensor
FAN
Stacker cover open SW
Transfer roller
AC inlet
AC-SW
Tag board
Tag transit board 1
Tag transit board 2 Tag transit board 3
IN
sensor
WRT
sensor
Toner inlet
sensor
Figure1-1
