Appendix D Network Interface
(1) Connector
• 8-pin modular jack
(2) Cable
• Category-5 non-shielded twisted pair cable with RJ-45 connector
(3) Signal
(4) Exterior
(5) Physical Size
a) Transfer method by CSMA/CD
b) Transfer protocol
1pin
(6) Protocol List
Protocol Family
Protocol used in
Printing (1)
Protocol Used in
Setting reference (2)
and Change (3)
Other Protocols
TCP/IP LPR
IPP
FTP
SMTP
HTTP
（
Other than
IPP
）
HTTP
Telnet
FTP
NetBEUI
SNMP
DHCP/BOOTP
AutoIP
DNS
UPnP
SLP
TCP, IP, ICMP, ARP
UDP,IPv6,LLTD,Windowa Relly
NetBEUI SMB, CIFS WINS NetBIOS
NetWare Q-Server over IPX
Q-Server over IP
R-Printer
N-Printer
NCP
SNMP
SPX, IPX, SAP, RIP
EtherTalk PAP NBP ELAP, AARP, DDP, AEP, ZIP, RTMP, ATP
EAP
(B420/B430/B440)
EAP-TLS,PEAP
PIN No. Signal name Direction Function
1 TXD+ FROM PRINTER Transmit Data+
2 TXD- FROM PRINTER Transmit Data-
3 RXD+ TO PRINTER Receive Data+
4 − − Not used
5 − − Not used
6 RXD- TO PRINTER Receive Data-
7 − − Not used
8 − − Not used
Packet type Support Remarks
Ethernet ll
IEEE802.3
IEEE802.3+IEEE802.2
IEEE802.3+IEEE802.2+SNAP
