4. ADJUSTMENT
43984801TH Rev.1
66 /
Oki Data CONFIDENTIAL
4. ADJUSTMENT
This chapter provides explains relating to the adjustment that is necessary while replacing part. Adjustment
is performed by modifying the value of parameter that is set on the EEPROM of main PCB board. Parameter
can be set by key operation that is from the operator panel. There are 3 kinds of maintenance mode (menu)
on this printer. While replacing part it is need to choose one of the mode.
4.1 Category and function of maintenance mode
•
Maintenance mode can be divided into User maintenance mode that is released to user, Engine
Maintenance Mode and System Maintenance Mode that are not released to user but for the only
use of maintenance personnel.
•
For renewing each category, push the button of
"
MENU
▲ "
and
"
MENU
▼ "
. After renewing the
last category, it returns to the initial category.
•
If want the displayed function to be effective, push the
「
SETUP
」
button.
•
For terminating the mode that is in category displaying, push the key of
「
ON LINE
」
and return to
operation mode.
4.4.1 User maintenance mode (Administrator Menu)
For Administrator Menu, push the button of
「
SETUP
」
and power Switch simultaneously.
After the category has been displayed, let go of the button
"
SETUP
"
.
Administrator Menu has the following function.
Category
Operation panel display
Default
value
Function
*
Only English is supported for panel display
Setting item
(Upper case)
Setting item
(Lower case)
OP MENU
ALL CATEGORY ENABLE
DISABLE
*
Sets category ALL Enable/Disable of User Menu. If
set to invalidation, user menu wont to be display. The
following setting item is not displayed if it is invalid.
When doing panel lock, must invalidate this menu.
INFORMATION
MENU
ENABLE
DISABLE
*
ISetting validation / Invalidation of INFORMATION
MENU category. If invalidate it the INFORMATION
MENU category of user menu is not displayed.
SHUTDOWN
MENU
ENABLE
DISABLE
*
Set Category SHUTDOWN MENU Enable/Disable.
Set to Disable, Category SHUTDOWN MENU of User
Menu is not displayed.
PRINT MENU ENABLE
DISABLE
*
Set Category PRINT MENU Enable/Disable.
Set to Disable, Category PRINT MENU of User Menu
is not displayed.
MEDIA MENU ENABLE
DISABLE
*
Set Category MEDIA MENU Enable/Disable.
Set to Disable, Category MEDIA MENU of User Menu
is not displayed.
SYS CONFIG
MENU
ENABLE
DISABLE
*
Set Category SYSTEM CONFIG MENU Enable/
Disable.
Set to Disable, Category SYSTEM CONFIG MENU
OF User Menu is not displayed.
PCL
EMULATION
ENABLE
DISABLE
*
Set Category PCL EMULATION MENU Enable/
Disable.
Set to Disable, Category PCL EMULATION MENU of
User Menu is not displayed.
PPR
EMULATION
ENABLE
DISABLE
*
Set Category PPR EMULATION MENU Enable/
Disable.
Set to Disable, Category PPR EMULATION MENU of
User Menu is not displayed. Except Japan Oriented.
[
Display Condition
]
"SYSTEM MAINTENANCE"-"PERSONALITY"-"IBM
PPR
III
XL" is ENABLE.
To Next Page
