7.3 Overview of modes
Bipolar Monopolar
Cutting BipolarCut Blend
PlasmaCut BlendCut
PK LoopCut FineCut
PK MorceCut PowerCut
PK PureCut PulseCut Fast
PK SoftCut PulseCut Slow
Pure
PureCut
Coagulation AutoCoag Fulgurate
BiSoftCoag ForcedCoag
HardCoag PowerCoag
PK Coag SoftCoag
PK SoftCoag Spray
SalineCoag SprayCoag
Additional modes within Olympus instruments
Special Olympus instruments, e.g. the POWERSEAL instruments, enable additional
modes. When such an instrument is connected to the UNIVERSAL socket, the ESG-410
automatically recognizes the instrument, and the modes and settings are accessible.
All required mode information of such instruments can be found in the corresponding
instrument’s instructions for use.
7.4 Description of modes
The following descriptions comply with the requirements of the standard IEC 60601-2-2.
1)
The crest factor is specied at rated load.
2)
The power level is the continuous power (W) which can be applied during the activation
of the electrosurgical generator. The actual applied power depends on the tissue
characteristics, e.g. resistance.
7.4.1 Description of the bipolar cutting modes
BipolarCut
Fast cutting with small coagulation zone. High Power Cut Support (HPCS) enables fast start
of cutting.
Control characteristics .....................................................................................................HPCS
Waveform ........................................................................Continuous sinusoidal, unmodulated
Crest factor
1)
............................................................................................................... 1.3 to 1.8
Range of power levels
2)
............................................................................................1 to 100 W
Effect levels ...................................................................................................................... 1 to 3
Maximum output voltage at effect level 1 ....................................................................... 425 V
p
Maximum output voltage at effect level 2 ....................................................................... 485 V
p
