98
Compatible equipment
Manufacturer
Model
Neutral electrode description
Covidien
E7510-25,
E7510-25DB*
P
atient weight 2.7...13.6 k
g
*Not licensed in accordance with Canadian law
.
15.3 Compatible foot switches
Description
Catalog number
Foo
t switch, double pedal
W
A91301W
Foo
t switch, double pedal, wireless
W
A91302W
Foo
t switch, single pedal
W
A91303W
97
99
Table of Contents
Table of Contents
3
Using this Document
7
User Instructions
7
Conventions Throughout this Document
7
Safety-Related Information in this Document
7
Safety Information
9
Intended Purpose
9
Contact
10
General Safety Notes
10
Product Description
19
Scope of Delivery
19
Product Functions
19
Operating Elements on the Hardware
21
Operating Elements on the Touchscreen
22
Popups and Messages
25
Symbols and Icons
26
Warranty
29
Installation
30
Safety Notes for Installation
30
General Inspection
30
Placement of the Electrosurgical Generator
30
Connection of Electrosurgical Generator to the Mains Electricity
31
Connection of Foot Switches
32
Connection of Peripheral Equipment
32
Connection for Automatic Smoke Evacuation
32
System Settings
36
Operation of the Touchscreen
36
Settings - Setup
36
Volume Control of Activation Tones
37
Brightness Control
38
Alarm Tones
38
Touch Tone
39
Languages
39
Date, Time and Format
40
Monopolar Modes
40
Startup Settings
41
Procedures
41
Assigning Foot Switches
42
Safe Use of Neutral Electrodes
44
Split Type and Non-Split Type Neutral Electrodes and CQM
44
Restriction to Only Split Type Neutral Electrodes
45
Safety Feature for Baby Neutral Electrodes
46
Conditions of the CQM Indicator
48
Selecting an Appropriate Neutral Electrode
49
Connection of a Neutral Electrode to the Electrosurgical Generator
49
CQM Indicator Verification
51
Before Use
52
Safety Notes for before Use
52
Inspection before Use
53
Overview of Modes
55
Description of Modes
55
Tissue Effects Depending on the Power Level and Effect Level
62
Use
64
Safety Notes for Use
64
Description of the Output Sockets
65
Connection of Instruments
67
Selection of Appropriate Output Settings
67
Automatic Instrument Recognition
69
Selecting a User-Defined Procedure
71
Activation of HF Output
71
Activating
73
Alarm System
77
Troubleshooting
78
After Use
83
Reprocessing of the ESG-410
84
General Information for Reprocessing
84
Cleaning
84
Disinfection
84
Reprocessing of Other HF Equipment
85
Maintenance
86
Regular Safety Checks
86
Maintenance Settings
87
Repair and Shipment
92
Repair
92
Shipment
92
Storage and Disposal
93
Storage
93
Disposal
93
Ordering Information
94
Compatible Equipment
95
System Chart
95
Compatible Neutral Electrodes
96
Compatible Foot Switches
98
Technical Data
99
Specifications for the ESG-410
99
Ambient Conditions for Operation, Storage and Transport
99
Plug Requirements
100
Resistance Range for CQM
100
Specifications for Cables
100
Specifications for the USB Flash Drive
100
Additional Information
101
Alarm System
101
Tone Information
102
Mode Characteristics According to IEC 60601-2-2
105
Characteristics of High Power Cut Support (HPCS)
106
Output Characteristic Diagrams
106
Electromagnetic Compatibility
133
Glossary
136
Index
140
Other manuals for Olympus ESG-410
