138
Chapter 5 Operation
VISERA VIDEO SYSTEM CENTER OTV-S7V
• Refer to Section 3.8, “Connection to image mixer unit UIM” to
connect the OTV-S7V, SCV-3 and UIM. Press a remote
control switch or “F4” key on the keyboard once to freeze the
image, and press it a second time to release the image.
Release the image by pressing a remote control switch
1. Refer to Section 5.12, “Remote control switches” and set a remote control
switch to “RELEASE”.
2. Refer to the SCV-3’s instruction manual for photography instructions.
3. Press the remote control switch once to expose one frame. The frame count
displayed on the SCV-3 increases.
Release the image by pressing a key on the keyboard
1. Refer to Section 5.13, “Setting a function to the keyboard” and set the “F4”
key to “RELEASE”.
2. Refer to the SCV-3’s instruction manual for photography instructions.
3. Press the “F4” key once to expose one frame. The frame count displayed on
the SCV-3 increases.
5.21 Photography and display with color video printer
OEP-3/OEP (not available in some countries)
The image can be released by pressing a remote control switch or a key on the
keyboard (optional).
• When controlling the image directly from the OEP-3/OEP,
refer to the appropriate instruction manual.
• To obtain sharp photographs without blurring, keep the
endoscope stationary when pressing the remote control
switch.
• When you would like to have remote control over the
OEP-3/OEP and Memory Card (types B, C and F only) at the
same time, set the remote control switch or “F4” key on the
keyboard to “REL.+DIG. CAP.”.
To Next Page
