Chapter 5 Operation
177
VISERA VIDEO SYSTEM CENTER OTV-S7V
The sub-image position setting is retained when the power is
turned OFF and the power cord is disconnected.
5.27 Multi freeze (installed in OTV-S7BOD-MF type
only)
The multi freezing images for moving object (e.g. vocal cord) can be displayed
on the video monitor.
Division number setting
The number of images can be set to 4 or to 9 by controlling the menu switches or
keyboard (optional).
1. Depress the menu switch “ ” for approximately 1 second or the “F1” key
on the keyboard to display the menu
By simultaneously pressing the keyboard’s “Shift” key and
“B.O.D.” key that is set “MULTI FREEZE”, you can jump to
step 6. For instructions on setting the “B.O.D.” key to “MULTI
FREEZE”, refer to Section 5.13, “Setting a function to the
keyboard”.
2. Depress the menu switches “ ” or “ ”, or the “///” key on the
keyboard to move the arrow “ ” to “B.O.D. CONTROL” (see Figure 5.89).
3. Depress the menu switch “ ” or the “Enter” key on the keyboard to display
the next menu.
4. Depress the menu switches “ ” or “ ”, or the “///” key on the
keyboard to move the arrow “ ” to “MULTI FREEZE” (see Figure 5.127).
To Next Page
