198
Appendix
VISERA VIDEO SYSTEM CENTER OTV-S7V
Operating environment
Transportation and storage environment
Specifications (when all B.O.D.s are installed in the
OTV-S7V)
Operating
environment
Ambient temperature
10 – 40
C (50 – 104F)
Relative humidity 30 – 85%
Air pressure 700 – 1060 hPa
(0.7 – 1.1 kgf/cm²)
(10.2 – 15.4 psia)
Transportation and
storage environment
Ambient temperature
25 to +70C
Relative humidity 10 – 90%
Atmospheric
pressure
700 – 1060 hPa
Power supply Voltage 100 – 240 V AC
(When using NTSC type with a
voltage which exceeds 120V AC,
use a power cord adapting to
each power supply voltage.)
Voltage fluctuation Within ± 10%
Frequency 50/60 Hz
Frequency fluctuation Within ± 1 Hz
Consumption electric
power
70 VA
Fuse rating 3.15 A, 250 V
Fuse size
ø 5
20 mm
Size Dimensions
298 (W) 87 (H) 390 (D) mm
Dimensions
(maximum)
301 (W) 95 (H) 394 (D) mm
Weight Type A: 6.1 kg
Type B: 6.5 kg
Type C: 6.6 kg
Type D: 6.3 kg
Type F: 6.6 kg
To Next Page
