182
Chapter 5 Operation
VISERA VIDEO SYSTEM CENTER OTV-S7V
Display the strobe images by pressing a key on the
keyboard
1. Refer to Section 5.13, “Setting a function to the keyboard” and set the
“MULTI FREEZE” function to the “B.O.D.” key on the keyboard.
2. Pressing the “B.O.D.” key toggles between turning the strobe images on
and off (see Figure 5.132).
5.28 Image orientation (type F and installed in
OTV-S7BOD-RT type only; see Section 2.5)
The image displayed on the video monitor can be rotated 180 by controlling the
menu switches or keyboard (optional).
• 180 DEG. ROTATION : display a rotated 180 image
• NORMAL : display a normal image
This rotated 180 image differs from one in section 5.25,
“Mirror and rotated images”, the menu and patient data are
displayed on the image.
Change the image quickly (keyboard only)
1. Refer to Section 5.13, “Setting a function to the keyboard” and set
“ORIENTATION” to the “B.O.D.” key.
2. Press the “B.O.D.” key that is set to “ORIENTATION”. Each time this switch
is depressed, the image cycles through “180 DEG. ROTATION” and
“NORMAL”.
Change the image by operating the menu
1. Depress the menu switch “ ” for approximately 1 second or the “F1” key
on the keyboard to display the menu.
By simultaneously pressing the keyboard’s “Shift” key and
“B.O.D.” key that is set to “ORIENTATION”, you can jump to
step 7. For instructions on setting the “B.O.D.” key to
“ORIENTATION”, refer to Section 5.13, “Setting a function to
the keyboard”.
To Next Page
