Olympus VISERA OTV-S7V User Manual

40
Chapter 3 Installation and Connection
VISERA VIDEO SYSTEM CENTER OTV-S7V
3.8 Connection to image mixer unit UIM
1. Turn the OTV-S7V and UIM OFF.
2. Connect the UIM to the OTV-S7V and SCV-3 or OEP-3/OEP as shown in
Figure 3.11 or 3.12.
• If the UIM is not being used in conjunction with the SCV-3 or
OEP-3/OEP, there is no need to connect the OEP and RGB
cables as shown in Figure 3.11 and 3.12.
• For details of connecting the video monitor and the OTV-S7V,
refer to Section 3.3, “Connection to a video monitor”.
