Chapter 3 Installation and Connection
VISERA VIDEO SYSTEM CENTER OTV-S7V
3.4 Connection to a video tape recorder
Turn the OTV-S7V and VTR OFF before attaching the VTR
remote control cable. Failure to do so, equipment damage
can cause.
1. Turn the OTV-S7V and VTR OFF.
2. Connect the VTR power cord to the isolation transformer.
3. Connect the isolation transformer’s power cord to a wall mains outlet.
4. When using the OEV143/203 with the SVO-9500MD/9500MDP, connect the
VTR as shown in Figure 3.6.
• The VTR remote control function is only available when using
the SVO-9500MD (NTSC) or SVO-9500MDP (PAL).
• For details of connecting the video monitor and the OTV-S7V,
refer to Section 3.3, “Connection to a video monitor”.
