52
Chapter 4 Inspection
VISERA VIDEO SYSTEM CENTER OTV-S7V
Chapter 4 Inspection
Before each case, inspect this instrument as instructed
below. Inspect other equipment used with this instrument as
instructed in their respective instruction manuals. Should the
slightest irregularity be suspected, do not use the instrument
and see Chapter 7, “Troubleshooting”. If the irregularity is still
suspected after consulting Chapter 7, contact Olympus.
Damage or irregularity may compromise patient or user
safety and may result in more severe equipment damage.
Prepare this instrument and other compatible equipment used with this
instrument before each use (shown in the “System chart” in the Appendix) for the
particular case. Refer to the respective instruction manual for each piece of
equipment.
4.1 Inspection with the power ON
Press the power switch to turn ON the OTV-S7V and confirm that power is being
supplied. The power indicator will illuminate and the indicators on the front panel
will light up.
Inspection if power fails to come on
If the power fails to come on, inspect the system as follows:
1. Confirm that the power cord is connected securely to a wall mains outlet and
the AC power inlet on the OTV-S7V.
2. Confirm that the fuses have not blown. If the fuses have blown, replace
them with new ones according to the following procedures.
If both of fuses are not blown, immediately turn the OTV-S7V OFF.
Remove the power cord from the wall mains outlet and contact Olympus.
• Turn the OTV-S7V OFF and remove the power cord from the
AC power inlet on the OTV-S7V before replacing the fuses
with new ones. Otherwise, electric shock may result.
• Only use the fuses listed below. Otherwise, fire or equipment
damage can result.
To Next Page
