Chapter 2 Nomenclature and Functions
VISERA VIDEO SYSTEM CENTER OTV-S7V
Chapter 2 Nomenclature and Functions
2.1 Symbols and descriptions
Power switch
Front panel
Rear panel
Power ON/OFF
Video connector Mode setting
Forward Maximum
Backward Minimum
Exposure White balance
Menu Up
TV in (type C only; see
Section 2.5)
Down
Caution,
refer to instructions.
Caution,
refer to instructions.
Equipotential terminal
Fuse Serial number
Alternating current
